Product Description
With its two inline, mirrored print heads, integrated printing and contour-cutting technology, and GREENGUARD Gold Certified Eco-Sol MAX 2 inks in 7 or 8-color configurations, the XR-640 large format printer/cutter with metallic and white ink delivers maximum versatility and productivity with unsurpassed image quality. Thousands of print service providers have built their business on the XR-640, with the ability to produce everything from banners, vehicle wraps and fine art to print/cut labels, decals, point-of-purchase displays and so much more.
Distinguishing Features
- Photorealistic printing up to 720 x 1440 dpi
- Print speeds of up to 528 sqft. per hour (49 m2/hr)
- Automated take-up system included
- Integrated tri-heater for fast drying
- Roland VersaWorks RIP software included
- CMYKLcLm + Light Black
- CMYKLcLm + White + Metallic
- CMYKLcLm + Light Black + White
- CMYKLcLm + Light Black + Metallic
State of the Art Print Engine
The XR-640 features two gold-plated 8-channel piezo inkjet heads with 180 nozzles per channel for high-speed, high-quality printing. With Roland Intelligent Pass Control technology and variable dot control producing droplets of seven different sizes, the XR-640 achieves smooth gradations, exceptional solid colors and superior photographic reproduction in all print modes. The print heads are arranged in an inline formation and configured in a mirrored pattern, virtually eliminating chromatic banding in bi-directional printing.
Advantage of Integrated Print/Cut
The ability to use a single device to take a print/cut job from start to finish creates a tremendous competitive advantage for print service providers. By automatically contour cutting printed graphics as soon as they finish printing, the XR-640 eliminates the need to reload and reposition graphics, saving valuable time and effort, and saving on the cost of a stand-alone cutter. With its included TU-2 take-up system, the Pro 4 is capable of performing long, unattended print/cut runs, or functioning as a stand-alone vinyl cutter.
Superior Print Results with Eco-Sol MAX® 2 Inks
GREENGUARD Gold Certified for indoor air quality, Eco-Sol MAX 2 eco-solvent inks produces rich, vibrant color that other inks simply can’t match. MAX 2 dries quickly and provides unmatched long-term outdoor durability, scratch and chemical resistance, plus a wide color gamut and a broad range of media options.Eco-Sol MAX 2 specialty inks expand your possibilities, allowing for stunning effects and adding value to any graphic. Roland’s Quadralign four-point optical registration system allows users to remove prints, laminate and reload them for precision cutting. Quadralign automatically realigns the cutting path and compensates for skew and distortion.
Light Black - Provides better reproduction of gray color gradients and more natural skin tones.
Metallic Silver - This silver ink can be printed as a spot color or combined with CMYK to produce over 500 striking metallic and pearlescent colors.
High-Density White - Allows for greater opacity on clear or dark substrates
| Printing technology | Dual Head Piezoelectric Inkjet | |||
| Media | Width | 10.2 to 64 in. (259 to 1625 mm) | ||
| Thickness | Maximum 39 mil (1.0 mm) with liner | |||
| Roll diameter | Maximum 8.3 in (210 mm) | |||
| Roll weight | Maximum 88 lbs (40 kg) | |||
| Core diameter | 3 in (76.2 mm) or 2 in (50.8 mm) | |||
| Printing Width | Max. 63 in. (1600 mm) | |||
| Ink cartridges | Type | Roland Eco-Sol MAX 2 Ink | ||
| Capacity | 440 cc CMYKLcLmLk - 220 cc Metallic and White | |||
| Colors | 9 Colors (cyan, magenta, yellow, black, light cyan, light magenta, light black, metallic, white) | |||
| Print resolution | Dots per in | Maximum 1,440 dpi | ||
| Print Modes | ||||
| Quality | Resolution | Pass Count | Speed | |
| Billboard (Banner) | 360x360 | 1 | 528.1 sqft/hr (49.1 m2/h) | |
| High Speed (Banner) | 540x360 | 2 | 351.9 sqft/hr (32.7 m2/h) | |
| 540x360 (V) | 3 | 232.4 sqft/hr (21.6 m2/h) | ||
| Standard (Banner) | 360x720 | 3 | 183.5 sqft/hr (17.0 m2/hr) | |
| 540x720 | 5 | 110.1 sqft/hr (10.2 m2/hr) | ||
| High Quality (Banner) | 720x1440 | 10 | 50 sqft/hr (4.6 m2/h) | |
| High Speed (Vinyl) | 540x360 | 3 | 232.4 sqft/hr (21.6 m2/h) | |
| Standard (Vinyl) | 360x720 | 4 | 166.1 sqft/hr (15.4 m2/h) | |
| 540x720 | 6 | 109.7 sqft/hr (10.2 m2/h) | ||
| High Quality (Vinyl) | 720x1440 | 10 | 48.7 sqft/hr (4.5 m2/h) | |
| Distance accuracy | Error of less than ±0.3% of distance traveled, or ±0.3 mm, whichever is greater | |||
| Media heating system | Print heater | Setting range for the preset temperature: 86 to 112°F (30 to 45°C) | ||
| Dryer | Setting range for the preset temperature: 86 to 122°F (30 to 50°C) | |||
| Connectivity | Ethernet (10BASE-T/100BASE-TX, automatic switching) | |||
| Power-saving function | Automatic sleep feature | |||
| Power requirements | AC 100 to 120 V ±10%, 8.2A, 50/60 Hz or | |||
| AC 220 to 240 V ±10%, 4.2A, 50/60 Hz | ||||
| Power consumption | During operation | 1530 w | ||
| Sleep mode | 47 w | |||
| Environmental | Power on | Temperature: 59 to 90°F (15 to 32°C) [68°F (20°C) or more recommended], Humidity: 35 to 80% RH (no condensing) | ||
| Power off | Temperature: 41 to 104°F (5 to 40°C), humidity: 20 to 80% RH (no condensation) | |||
| Dimensions (with stand) | 116[W] x 47.8[D] x 49.6[H] in (2948[W] x 1214[D] x 1260[H] mm) | |||
| Weight (with stand) | 452 lb (205 kg) | |||
| Included items | XR-640 stand, cleaning liquid cartridges, power cord, media clamps, blade, blade holder, replacement blade for sheet cutter, Roland VersaWorks RIP Software, cleaning kit, manual, etc. | |||
Roland VersaWorks System Requirements
Application software compatible with Cutting and Print&Cut
| |||||||||||||||||||||||||||||||||||||||||
